Elegoo 3D-Drucker Jupiter 2
The Elegoo Jupiter 2 is a state‑of‑the‑art large‑format MSLA 3D printer designed for users who demand exceptional detail accuracy, high process stability and a generous build volume. Its impressive 14‑inch mono LCD with 16K resolution delivers outstanding sharpness and uniform exposure across the entire print area, enabling highly detailed and consistent results.
With a spacious build volume of 302 × 162 × 300 mm, the Jupiter 2 is ideal for producing large models, multiple parts in a single run or efficient small‑batch production. The COB LED light engine combined with a Fresnel collimation lens ensures precise and even light distribution, resulting in reliable print quality from edge to edge.
The Jupiter 2 features fully automatic multi‑point leveling, an integrated resin tank heater for optimal viscosity and an intelligent resin management system with automatic feeding and pump‑back functionality. The quick‑swap FEP/ACF system significantly reduces maintenance time, while the built‑in camera allows convenient real‑time monitoring.
| Printing Technology | MSLA / LCD resin printing |
| LCD Panel | 14‑inch mono LCD, 16K resolution |
| XY Resolution | 20 × 26 µm |
| Build Volume | 302 × 162 × 300 mm |
| Light Source | COB LED + Fresnel collimation lens |
| Layer Thickness | 0.01–0.2 mm |
| Max Print Speed | up to 70 mm/h |
| Resin Management | Automatic resin feeding + automatic resin pumping‑back |
| Resin Tank Heating | up to 30 °C |
| Leveling | Fully automatic multi‑point leveling |
| FEP/ACF System | Quick‑swap film system |
| Camera | Integrated monitoring camera |
| Enclosure | Dual‑door design, sealed light engine |
| Display | 5‑inch touchscreen |
| Connectivity | USB, Wi‑Fi |
| Special Features | Smart resin management, heated tank, 16K panel, camera, fast film replacement |
| Technical characteristic | Value |
|---|---|
| Item ID | 1348 |
| Condition | New |
| Age rating | 3 and older |
| Variation ID | 50.101.081300 |
| Model | 200502 |
| Manufacturer | Elegoo |
| Manufacturing country | China |
| Content | 1 piece |
| Weight | 34000 g |
| Net weight | 26000 g |
| Dimensions | 550×600×750mm |
| Customs tariff number | 84778020 |
