TwoTrees CNC Fräsmaschine TTC-H80

The Two Trees TTC-H80 CNC router is the all-rounder for powerful projects that leave an impression. Large surface area, smart operation and plenty of power - all in one stylish package!

Generous work surface

With an impressive work surface of 1000 x 2000 x 100 mm, the TTC-H80 milling machine offers plenty of space for your ideas. Whether you have medium-sized projects or really big plans, this CNC machine makes it possible and increases your efficiency by up to 300 %!

Thanks to its ability to emboss, add depth and texture, you can conjure up functional one-offs in no time at all - from customised pieces of furniture to detailed decorative objects.

One-click control - CNC meets laser engraving!

The 3.5-inch smart touchscreen makes controlling the TTC-H80 super easy - one click is all it takes to switch between CNC routing and laser engraving!

There's also a clever safety package that lets you work worry-free:

• Spindle switch-off,
• Emergency stop switch,
• Laser protection.

These keep your back free so that you can concentrate fully on your creativity.

Further features:

• Slim design with clear lines,
• Simple assembly,
• Modularly expandable,
• Compatible with common software (Carveco Maker, Artcam, EASEL, Fusion 360, etc.),
• Suitable for wood, metal, plastic, acrylic glass, etc.

Machine dimensions: 1292.5 x 2336.8 x 404.5 mm
Material: Aluminum alloy
Working area: 1000 x 2000 x 100 mm
Max. speed: 18000 mm/min
Engraving accuracy: 100 + 0.05 mm
CAM software: Artcam, Fusion360, EASEL, Carveco Maker
Display: 3.5-inch touchscreen
Display functions: Motion control, emergency stop button, speed control, laser/CNC switch, language switching, online help
Spindle: 775 brush motor, 500 W spindle
Engraving method: USB, 2.4 GHz Wi-Fi, TF card
Compatible materials: Plywood, MDF, solid wood, acrylic, carbon fiber, aluminum, copper, stainless steel
